VBC-4075-C11 650TVL 960H Box Camera, ElectronicD/N, DWDR, DNR, LV (No Lens, CS mount)
Image Sensor 1/3" CCD, 960H
Horizontal resolution 720 TVL
Minimum Illumination Color: 0.05 lux B/W: 0.01 lux (true D/N version), F1.2, 30IRE)
Lens type Manual, DC Iris DC Iris drive
Signal-to-Noise Ratio 52 dB
Dimensions 58 x 66 x 122 mm.
Supply Voltage 12VDC/24VAC
Power Consumption 2.4 W max. / 0.2 A
DINION 4000 cameras are compact analog camerasthat offer excellent resolution in variable lightingconditions, day or night. The high performance 960H1/3‑inch CCD sensor provides a resolution of 720TVL.The cameras are an ideal solution for demandingscene conditions. The backlight compensation andhighlight compensation features optimize the imagevisibility in high-contrast areas, automaticallycompensating for bright backgrounds and strong lightsources.The cameras are easy to install and parameters can beset individually. Privacy zones and motion detectionfunctions can be set up in the handy camera menusystem.The true day/night version automatically switches fromcolor to monochrome using a mechanical IR filterdepending on the available light.
VBC-4075-C11 | Technical Specifications
| Image Sensor |
960H, 1/3" CCD, sensor resolution 720TVL |
| System |
PAL or NTSC |
| Total pixels (H x V) |
1020 x 596 (PAL)1020 x 508 (NTSC) |
| Effective pixels (H x V) |
976 x 582 (PAL)976 x 494 (NTSC) |
| Video Output |
Composite: 1 Vpp, 75 Ohm |
| Sync. System |
Internal sync., Line-lock |
| S/N Ratio (sharpness, AGC off) |
52 dB min. |
| Minimum Illumination (F1.2, 50IRE) |
Color: 0.1 lx B/W: 0.02 lx (true D/N version) |
| Minimum Illumination (F1.2, 30IRE) |
Color: 0.05 lx B/W: 0.01 lx (true D/N version) |
| Manual shutter |
1/50 – 1/10,000 (PAL)1/60 – 1/10,000 (NTSC) |
| Digital Noise reduction |
2DNR |
| White Balance |
ATW, Push, User1, User2, Anti CR, Manual, Push lock |
| Light compensation |
OFF/BLC/HLC |
| Digital Dynamic Engine |
On, Off |
| AGC |
On, Off |
| Day/Night |
Auto, Color, B/W |
| Burst |
On, Off |
| Motion detection |
4 programmable zones |
| Privacy |
8 programmable zones (4 zones when motion detection is on) |
| Mirror |
On (horizontal), Off |
| Sharpness |
0 ‑ 255 |
| Alarm input (true D/N version only) |
Night mode active profile switching, 3.3 V nominal, +40 VDC max. |
| Alarm output(true D/N version only) |
Night mode active, 30 VAC or +40 VDC, max. 0.5 A continuous, 10 VA |
| OSD language |
English, Japanese, German, French, Russian, Portuguese, Spanish, Simplified Chinese |
| Lens type |
Manual, DC IrisDC Iris drive: 50 mA max. |
| Lens mount |
CS (max. lens protrusion 5 mm [0.2 in])C-mount compatible with optional adapter ring |
| Tripod mount |
Bottom (isolated) and top 1/4-inch 20 UNC |
| Supply Voltage(VBx-4075-C11, VBx-4075-C21) |
12 VDC / 24 VAC |
| Supply Voltage(VBx-4075-C51) |
230 VAC |
| Power Consumption (true D/N version) |
3.6 W max. / 0.3 A |
| Power Consumption (electronic D/N version) |
2.4 W max. / 0.2 A |
| Dimensions (without lens) |
58 x 66 x 122 mm2.28 x 2.6 x 4.8 in |
| Weight (12 VDC/24 VAC) |
500 g (1.10 lbs) without lens |
| Weight (230 VAC) |
600 g (1.32 lbs) without lens |
| Operating Temperature |
-20 °C to +55 °C (-4 ºF to +131 ºF) |
| Operating Humidity |
20% to 90% RH |
| Storage Temperature |
-40 °C to +70 °C (-40 ºF to +158 ºF) |
| Storage Humidity |
up to 98% RH |
